Autel MaxiIM IM608 Diagnostic & Key Programming Tool ECU Coding Replace Auro OtoSys IM600 & MX808IM
$3 999.00
In stock
Product Details
1.Samsung Exynos 5260(2GB ROM)
2.10.1”1024x768 LCD capacitive touchscreen
3.Internal reliable 64GB Memory
4.Android Operating System for fast boot-up and multitasking
5.Powerful combination of key programming/all system diagnostics/advanced maintenance services
6.Smart Mode for guided and automated key learning
7.Expert Mode for advanced key learning
8.Read PIN/CS (all key lost) , key generation, key learning, remote learning
9.IMMO ECU reset/adaptation, refresh/coding
10.Transpronder read/write, EEPROM/MCU read/write
11.Powerful OE level diagnostics for more than 80 US, Asian and European makes and models
12.Advanced maintenance services including EPB, DPF, SAS, Oil reset, BMS and TPMS sensor ID relearn
Operating System Android™ 4.4.2, KitKat
Processor Samsung Exynos hexa-core Processor (1.3GHz Quad-core ARM Cortex-A7 + 1.7GHz Dual-core ARM Cortex-A15)
Memory 2GB RAM & 64GB On-board Memory
Display 10.1-inch LED capacitive touch screen with 1920x1200 resolution
Connectivity: Wi-Fi (802.11 a/b/g/n/ac) USB: 2.0 BT v.2.1 + EDR SD Card (Support up to 32GB) HDMI
Protocols: ISO 9142-2, ISO 14230-2, ISO 15765-4, K/L-Line, Flashing Code, SAE-J1850 VPW, SAE-J1850 PWM, CAN ISO 11898, Highspeed, Middlespeed, Lowspeed and Singlewire CAN, GM UART, UART Echo Byte Protocol, Honda Diag-H Protocol, TP 2.0, TP 1.6, SAE J1939, SAE J1708, Fault-Tolerant CAN
Read & Clear Fault Codes | Short description & code provided (can clear faults & warning lights)
• Service Functions | Oil light / EPB / BMS / SAS / DAF etc
• Access Live Data | Data from the ECU/Modules/sensors displayed in real-time (Oxygen sensor-rich/lean etc.)
• Actuation/Component Testing | Actuate (switch on/off) to diagnose functionality (relays, fans, locks etc.)
• Coding Functions | Allows you to change vehicle parts that need to be ‘coded’ (Injectors, ABS, starters etc.)
• Flashing/Reprogramming | Advanced updating/coding of ECU’s online through a J2534 pass-through flashing device
• Advanced Key Programming | IMMO functions, Transponder read/write/identify, MCU/EEPROM chip read/write with XP 400 module
